V2 HYPERFOR 4000-I - Page 40

ENGLISH
- 38 -
3.2 - MOUNTING THE RACK
1. Releasethemotorandturnthegate
completelyopen.
2. Fixalltherackelementstothegate,
makingsurethattheystandatthesame
heightthanthemotorpinion.
The rack MUST BE positioned 1 or 2 mm
over the pinion of the motor all the
gate length.
3.3 - FIXING OF THE MOTOR
Checkthefollowingpoints:
1. themotormustbeonalevelledsurface
andperfectlyparalleltothegate
2. thedistancebetweenpinionandrack
mustbe
1or2mm.Ifneeded,adjustthe4grains
3. therackmustbetruedupwiththe
pinionofthemotor
4. theminimumdistancebetweenthe
maximumoverallofthegateandthe
caseofthepinionofthemotormustbe
ofatleast5mm
5. Checktheaboveindicatedconditions
andproceedxingthe4boltsD
anchoringthemotortotheplate.
174mm
224mm
2mm
216mm
>5 mm
D
