V7 D22W12 User Manual

1. The following frequency range is the working period. If the entered mode between below
period but not match the frequency of supported timing, display optimization would not be
assured. If the entered mode is out of the working period, the display will be blanking
(just show “INPUT SIGNAL OUT OF RANGE”) then go to power saving.
2. Basically, mode judgment is regardless the sync polarity except both or more modes that
are all belong to the supported timing list and could be judged by sync polarity only.
3. In the meantime, real entered frequency of the supported timing is not requested exactly.
4. Normalization of VGA card’ s deviation will be acceptable.
5. Horizontal Frequency
6. Vertical Frequency
- 8 -
Technical Features and Specifications
Interface Frequency
30 ~ 82KHz
56 ~ 76Hz
Net
Net
Tilt Angle
473.8(H)x296.1(V)mm
Analog
Digital
Operating
Condition
Storage
Condition
0.282(H)*0.282(V)mm
D-sub
DVI-D(Optional)
-5°~20°
About 4.9kg
About 510˄W˅x 424Hx 202˄D˅mm
AC
Consumption
AC
100~240V, 50Hz/60Hz,1.2A
Temperature
Humidity
Altitude
Temperature
Humidity
Altitude
Active:<55W/Standby:<2W
5°C to 40°C
-20°C to 60°C
20% to 80% (No Condensation)
Under 10,000 fts
5% to 80% (No Condensation)
Under 40,000 fts
Item
Description
Panel
Display Size
Pixel Pitch
Connector
Tilt
Weight
Power
Dimensions
(W x H x D)

V7 D22W12 Specifications

General

3D	No
HD type	-
Aspect ratio	16:10
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	1000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Digital vertical frequency	56 - 76 Hz
Digital horizontal frequency	31.5 - 83 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1680 x 1050 (WSXGA+)
Bandwidth	0.14 GHz
Power requirements	100 - 240 VAC
DVI-I ports quantity	0
RMS rated power	3 W
Number of speakers	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	55 W
Certification	CE, cUL, FCC, CCC, TCO’03, C-Tick
Product color	Black
Panel mounting interface	100 x 100 mm
Sustainability certificates	ENERGY STAR
Package depth	134 mm
Package width	569 mm
Package height	480.5 mm
Package weight	6600 g

Weight and Dimensions

Depth (with stand)	202 mm
Height (with stand)	423 mm
Weight (with stand)	4900 g
Depth (without stand)	56 mm
Width (without stand)	510 mm
Height (without stand)	348 mm
Weight (without stand)	4300 g
