- 7 -

Troubleshooting

1. Check if the monitor is turned on (press the button again).

2. Check if the power cord is properly connected to the monitor and power outlet.

3 .Check if there is electricity coming from the power outlet (use another device to check for power).

1 Check if your computer is turned on.

2 Ensure the computer is not in power saving mode (move the mouse or press a key on the keyboard

to wake up the computer).

3 Check if the video signal cable is properly connected to the monitor and computer.

Symptom Check Items

1 Check if your computer is turned on.

2 Check if the video signal cable is properly connected to the monitor and computer.

1. Ensure that the resolution and/or refresh rate is set correctly.

1.No picture

2.LED indicator is not lit.

1.No picture

2.LED indicator is orange

1.Picture shows “ NO SIGNAL INPUT ”

1.Picture shows “ INPUT SIGNAL OUT OF RANGE ”

Important

Make sure your display setup is under WSXGA 1680*1050,60Hz

Other manuals for V7 D22W12

Questions and Answers:

Need help?

Do you have a question about the V7 D22W12 and is the answer not in the manual?

General

3D	No
HD type	-
Aspect ratio	16:10
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	1000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Digital vertical frequency	56 - 76 Hz
Digital horizontal frequency	31.5 - 83 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1680 x 1050 (WSXGA+)
Bandwidth	0.14 GHz
Power requirements	100 - 240 VAC
DVI-I ports quantity	0
RMS rated power	3 W
Number of speakers	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	55 W
Certification	CE, cUL, FCC, CCC, TCO’03, C-Tick
Product color	Black
Panel mounting interface	100 x 100 mm
Sustainability certificates	ENERGY STAR
Package depth	134 mm
Package width	569 mm
Package height	480.5 mm
Package weight	6600 g
