Vacon CX - Parameters Group 1; Parameter Table

VV
VV
V
aconacon
aconacon
acon Page 5
Multi-purpose Control Application IIMulti-purpose Control Application II
Multi-purpose Control Application IIMulti-purpose Control Application II
Multi-purpose Control Application II
Vacon Plc Phone: +358-(0)201 2121 Fax: +358-(0)201 212 205
Service: +358-40-8371 150 E-mail: vacon@vacon.com
*) If 1
..
..
. 2 >motor synchr. speed, check suitability for motor and drive system.
Code Parameter Range Step Default Custom Description Page
1.1 Minimum frequency 0—120/500 Hz 1 Hz 0 Hz 6
1.2 Maximum frequency 0—120/500 Hz 1 Hz 50 Hz *) 6
1.3 Acceleration time 1 0.1—3000 s 0.1 s 3 s Time from f
min
(1.1) to f
max
(1.2) 6
1.4 Deceleration time 1 0.1—3000 s 0.1 s 3 s Time from f
max
(1.2) to f
min
(1.1) 6
1.5 Reference selection 0—15 1 0 0 = U
in
3 = U
in
– I
in
1 = I
in
4 = I
in
– U
in
2 = U
in
+ I
in
5 = U
in
* I
in
6 = U
in
joystick control
7 = I
in
joystick control
8 = Signal from internal motor pot.
9 = Signal from internal motor pot.
reset if Vacon unit is stopped
6
10 = Signal from internal motor
pot. (stored in menory over
mains break
11= Min (U
in
, I
in
)
12 = Max (U
in
, I
in
)
13 = Panel reference r1
14 = Max reference
15 = U
in
/I
in
selection
1.6
Jogging speed
reference
f
min
– f
max
(1.1) (1.2)
0.1 Hz 5 Hz 7
1.7 Current limit 0.1—2.5 x I
nCX
0.1 A 1.5 x I
cCX
Output current limit [A] of the unit 7
1.8 U/f ratio selection 0—210
0 = Linear
1 = Squared
2 = Programmable U/f ratio
7
1.9 U/f optimisation 0—110
0 = None
1 = Automatic torque boost
8
1.10
Nominal voltage of the
motor
180—690 1 V
230 V
400 V
500 V
690 V
Vacon range CX/CXL2
Vacon range CX/CXL/CXS4
Vacon range CX/CXL/CXS5
Vacon range CX6
9
1.11
Nominal frequency of
the motor
30—500 Hz 1 Hz 50 Hz f
n
on the rating plate of the motor
9
1.12
Nominal speed of the
motor
300—20000 rpm 1 rpm 1440 rpm
n
n
on the rating plate of the motor
9
1.13
Nominal current of the
motor
2.5 x I
nCX
0.1 A I
nCX
I
n
on the rating plate of the motor 9
180—250 230 V Vacon range CX/CXL2
380—440 400 V Vacon range CX/CXL/CXS4
380—500 500 V Vacon range CX/CXL/CXS5
1.14 Supply voltage
525—690 690 V Vacon range CX6
9
1.15 Parameter conceal 0—110
0 = All parameter groups visible
1 = Only group 1 visible
9
1.16 Parameter value lock 0—110
0 = Parameter changes enabled
1 = parameter changes disabled
9
STOP
STOPSTOP
STOP
STOP
STOPSTOP
STOP
STOP
STOP
STOPSTOP
STOP
STOP
STOPSTOP
STOP
STOP
STOPSTOP
STOP
STOP
STOPSTOP
STOP
STOP
STOPSTOP
STOP
Note!Note!
Note!Note!
Note!
STOP
STOPSTOP
STOP
= Parameter value can be changed only when the frequency converter is stopped. (Continues)
Table 5-1. Group 1 basic parameters
