Vacon CX Installation Manual

Page 2 (1 5 ) Vacon
I/ O-expander board installation (Vacon CXS-range)
Vacon Plc Tel: +3 58 -2 01 2 1 2 1 Fax: +3 5 8-20 1 2 1 2 2 05
Service: +3 5 8 -4 0 -8 37 1 1 50 E-mail: vacon@vacon.com
http:/ / w ww.vacon.com
1 GEN ERAL
Due to the compact frame size of the Vacon CXS series all I/ O -expander boards need
to be installed in a separate box (Vacon CXSO PTBKIT), except the smaller, specifically
for Vacon CXS designed boards (Vacon CX1 0 4 O PT, CX1 0 5 O PT, CX1 0 7 O PT,
CX1 08 O PT). If ordered together with the option board these will be preinstalled.
1.1 Vacon CX100OPT
The available I/ O can be increased by using the Vacon CX1 0 0 O PT I/ O -expander
board:
- 5 digital inputs (standard signals)
- 2 analogue inputs (standard signals)
- 3 relay outputs (standard signals)
- analogue output (programmable)
- thermistor input (can be directly connected to the motor
thermistors to monitor the motor temperature)
- encoder input
Typical use: Closed Loop Vector Control
1.2 Vacon CX101OPT
The available I/ O can be increased by using the Vacon CX1 0 1 O PT I/ O -expander
board:
- 5 digital inputs (standard signals)
- relay output (standard signal)
- thermistor input (can be directly connected to the motor thermistors to monitor
the motor temperature)
Typical use: thermistor input required
1.3 Vacon CX102OPT
The available I/ O can be increased by using the Vacon CX1 0 2 O PT I/ O -expander
board:
- 5 digital inputs (standard signals)
- 2 analogue inputs (standard signals)
- 3 relay outputs (standard signals)
- analogue output (programmable)
- thermistor input (can be directly connected to the motor thermistors to
monitor the motor temperature)
- encoder input
Typical use: Closed Loop Vector Control
1.4 Vacon CX103OPT
The available I/ O can be increased by using the Vacon CX1 0 3 O PT I/ O -expander
board:
- 5 digital inputs (standard signals)
- 3 relay outputs (standard signals)
- analogue output (programmable)
- thermistor input (can be directly connected to the motor thermistors to monitor
the motor temperature)
Typical use: thermistor input and additional analogue output required
