I/ O-expander board installation (Vacon CXS-range)
Vacon Plc Tel: +3 5 8 -2 0 1 21 21 Fax: +3 5 8 -2 0 1 2 1 2 2 0 5
Service: +3 5 8 -4 0 -8 37 1 1 50 E-mail: vacon@vacon.com
http:/ / w ww.vacon.com
1.5 Vacon CX104O PT
The available I/ O can be increased by using the Vacon CX1 0 4 O PT I/ O -expander
board:
- encoder input
Typical use: Closed Loop Vector Control
1.6 Fieldbus boards
Vacon fieldbus boards can be installed in the Vacon CXS range frequency converters
as I/ O -expander boards. The needed information to install/ commission fieldbus
boards can be found in the respective Vacon fieldbus manual.
- Vacon CX 2 0 0 O PT (Interbus-S)
- Vacon CX 2 01 O PT (M odbus)
- Vacon CX 2 0 2 O PT (Profibus-DP)
- Vacon CX 2 0 3 O PT (LonW orks)
- Vacon CX 2 0 4 O PT (C -b us)
- Vacon CX 2 0 5 O PT (SDS-bus)
