Active Front End (AFE)
vacon • 31
Local contacts: http://drives.danfos
s.com/danfoss-drives/
local-contacts/
4
Figure 12. Optical cable adapte
r board
Figure 13. Optical cable termin
als in the unit (FI13 ex
ample)
Optical terminals on adapter boar
d
H1
Gate contr
ol
enable
H2
Phase U contr
ol
H3
Phase V contr
ol
H4
Phase W contr
ol
H5
ADC synchr
onization
H6
V
aconBus data fr
om contr
ol board t
o ASIC
H7
V
aconBus data fr
om ASIC to contr
ol boar
d
32
34
