vacon • 40 Active Front End (AFE)
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
NOTE! All fuses are flush-end type. If some other type is needed, contact your distributor.
4.11.2.2 DC fuses
NOTE! All fuses are flush-end type. If some other type is needed, contact your distributor.
Table 15. Mersen AC fuse selection, mains voltage 380–500 Vac, North-America
Module AC fuses
Type Code
Enclosure
size
Mersen
type [aR]*
U
N
[V]
I
N
[A]
Size Q'ty
AFE
NXA_0168 5 FI9 PC32UD69V400TF 690 400 32 3
NXA_0205 5 FI9 PC32UD69V400TF 690 400 32 3
NXA_0261 5 FI9 PC32UD69V400TF 690 400 32 3
NXA_0385 5 FI10 PC33UD69V700TF 690 700 33 3
NXA_0460 5 FI10 PC33UD69V700TF 690 700 33 3
NXA_1150 5 FI13 PC44UD75V18CTQ 750 1800 44 3
NXA_1300 5 FI13 PC44UD75V18CTQ 750 1800 44 3
Table 16. Mersen DC fuse selection, mains voltage 465–800 Vdc
Module DC fuses
Type Code
Enclosure
size
Mersen type [aR]*
U
N
[V]
I
N
[A]
Size Q'ty
AFE
NXA_0168 5 FI9 PC73UD13C400TF 1250 400 73 2
NXA_0205 5 FI9 PC73UD13C400TF 1250 400 73 2
NXA_0261 5 FI9 PC73UD13C500TF 1250 500 73 2
NXA_0385 5 FI10 PC73UD13C800TF 1250 800 73 2
NXA_0460 5 FI10 PC73UD95V11CTF 950 1100 73 2
NXA_1150 5 FI13 PC84UD11C22CTQ 1100 2200 84 2
NXA_1300 5 FI13 PC84UD11C24CTQ 1100 2400 84 2
