Vacon NXP series Applications Manual

4.4.8 PROTECTIONS (CONTROL KEYPAD: MENU M2 -> G2.7)
Table 31: Protections, G2.7
Index Parameter Min Max Unit Default Cust ID Description
P2.7.1
Response to 4 mA
reference fault
0 5 0 700
0 = No response
1 = Warning
2 = Warning+Pre-
vious Freq.
3 = Wrng+Preset-
Freq 2.7.2
4 = Fault, stop acc.
to 2.4.7
5 = Fault, stop by
coasting
P2.7.2
4 mA reference
fault frequency
0.00 P2.1.2 Hz 0.00 728
P2.7.3
Response to
external fault
0 3 2 701
0 = No response
1 = Warning
2 = Fault, stop acc.
to 2.4.7
3 = Fault, stop by
coasting
P2.7.4
Input phase
supervision
0 3 3 730
P2.7.5
Response to
undervoltage fault
0 1 0 727
0 = Fault stored in
history
Fault not stored
P2.7.6
Output phase
supervision
0 3 2 702
0 = No response
1 = Warning
2 = Fault, stop acc.
to 2.4.7
3 = Fault, stop by
coasting
P2.7.7
Earth fault protec-
tion
0 3 2 703
P2.7.8
Thermal protec-
tion of the motor
0 3 2 704
P2.7.9
Motor ambient
temperature fac-
tor
-100.0 100.0 % 0.0 705
P2.7.10
Motor cooling fac-
tor at zero speed
0.0 150.0 % 40.0 706
P2.7.11
Motor thermal
time constant
1 200 min Varies 707
P2.7.12 Motor duty cycle 0 150 % 100 708
MULTI-STEP SPEED CONTROL APPLICATION VACON · 91
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
4

Vacon NXP series Specifications

General

Communication interfaces	RS-485, Ethernet
Storage temperature range	-40°C to +70°C
Dimensions	Varies by model
Weight	Varies by model
Product series	NXP
Voltage range	200 V to 690 V
Input voltage range	200 V to 690 V
Frequency range	0 Hz to 500 Hz
Control method	Vector control
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Enclosure classes	IP21, IP54
Braking chopper	Built-in or external
EMC filter	Built-in or external
Communication protocols	Modbus, Profibus, CANopen, Ethernet
Operating temperature range	-10°C to +50°C
Humidity range	5% to 95% (non-condensing)
Cooling method	Air-cooled or liquid-cooled
