Information
11.2 WorkStation, inputs and outputs.
Pressing the WorkStation 1 and WorkStation 2 buttons in the top menu row will take you to pages
containing detailed information on WorkStation inputs and outputs.
The green icon indicates which information is being displayed.
Figure 11.2 WorkStation 1, inputs
A.
Inputs. Shows a list of the current incoming signals to WorkStation.
B.
Outputs. Shows a list of the current outgoing signals from WorkStation.
C.
Other. Shows software information for WorkStation and current power supply.
28 903099-en-gb; 19.01.2021
