Electrical system
13 Electrical system
13.1 RD 300 – 400 S/C
WS1 Port Pin Function Type
1 1
Level Guard, Seed Analogue In
1 2
Level Guard, Seed Digital In
1 3
Level Guard, Seed
12 V
1 4
Level Guard, Seed Ground
2 1
Level Guard, Fertilizer Analogue In
2 2
Level Guard, Fertilizer Digital In
2 3
Level Guard, Fertilizer
12 V
2 4
Level Guard, Fertilizer Ground
3 1
Seed Motor speed, input Digital In
3 2
3 3
Seed Motor speed, input
12 V
3 4
Seed Motor speed, input Ground
4 1
Fertilizer Motor speed, input Digital In
4 2
4 3
Fertilizer Motor speed, input
12 V
4 4
Fertilizer Motor speed, input Ground
5
1
Rotation Guard, BioDrill Right Digital In
5
2
5
3
Rotation Guard, BioDrill Right
12 V
5
4
Rotation Guard, BioDrill Right Ground
6 1
Radar Digital In
6 2
6 3
Radar
12 V
6 4
Radar Ground
7
1
Tramline Seed Right
Rotation Guard, Seed Right
Digital In
7
2
Tramline Seed Right Digital Out
7
3
Tramline Seed Right
Rotation Guard, Seed Right
12 V
7
4
Tramline Seed Right
Rotation Guard, Seed Right
Ground
8 1
Tramline Seed Left
Rotation Guard, Seed Left
Digital In
36 903099-en-gb; 19.01.2021
