Electrical system
WS1 Port Pin Function Type
8 2
Tramline Seed Left Digital Out
8 3
Tramline Seed Left
Rotation Guard, Seed Left
12 V
8 4
Tramline Seed Left
Rotation Guard, Seed Left
Ground
9 1
Level Guard, BioDrill Digital In
9 2
Level Guard, BioDrill Digital In
9 3
Level Guard, BioDrill
12 V
9 4
Level Guard, BioDrill Ground
10 1
LowLift switch Analogue
10 2
Digital In
10 3 12 V
10 4
LowLift switch Ground
11 1
AutoCheck sensor Analogue
11 2
11 3
AutoCheck sensor
12 V
11 4
AutoCheck sensor Ground
12 1
12 2
Control, main cylinder
PWM Out
12 3 12 V
12 4
Control, main cylinder Ground
13 1
13 2
Control, adjustment cylinder
PWM Out
13 3 12 V
13 4
Control, adjustment cylinder Ground
14 1
14 2
Lift Stop
PWM Out
14 3 12 V
14 4
Lift Stop Ground
15 1
15 2
Pre-emergence marker
PWM Out
15 3 12 V
15 4
Pre-emergence marker Ground
903099-en-gb; 19.01.2021 37
