Electrical system
18 1
Tramline Fertilizer Right / Rotation
Guard, Fertilizer Right (RDC)
Tramline BioDrill Right (RDS)
Digital In
18 2
Tramline Fertilizer Right (RDC)
Tramline BioDrill Right (RDS)
Digital Out
18 3
Tramline Fertilizer Right / Rotation
Guard, Fertilizer Right (RDC)
Tramline BioDrill Right (RDS)
12 V
18 4
Tramline Fertilizer Right / Rotation
Guard, Fertilizer Right (RDC)
Tramline BioDrill Right (RDS)
Ground
19 1
Tramline Fertilizer Left / Rotation
Guard, Fertilizer Left (RDC)
Tramline BioDrill Left (RDS)
Digital In
19 2
Tramline Fertilizer Left
Tramline BioDrill Left (RDS)
Digital Out
19 3
Tramline Fertilizer Left / Rotation
Guard, Fertilizer Left (RDC)
Tramline BioDrill Left (RDS)
12 V
19 4
Tramline Fertilizer Left / Rotation
Guard, Fertilizer Left (RDC)
Tramline BioDrill Left (RDS)
Ground
20 1
Digital In
20 2
Marker, Right
PWM Out
20 3 12 V
20 4
Marker, Right Ground
21 1
Digital In
21 2
Marker, Left
PWM Out
21 3 12 V
21 4
Marker, Left Ground
22 1
Analogue In
22 2
Seed Motor speed, output
PWM Out
22 3 12 V
22 4
Seed Motor speed, output Ground
23 1
Digital In
23 2
Fertilizer Motor speed, output (RDC)
BioDrill Motor speed, output (RDS)
PWM Out
