Electrical system
23 3 12 V
23 4
Fertilizer Motor speed, output (RDC)
BioDrill Motor speed, output (RDS)
Ground
24 1
Rotation Guard, BioDrill Left Digital In
24 2
24 3
Rotation Guard, BioDrill Left
12 V
24 4
Rotation Guard, BioDrill Left Ground
25 1
Mini-remote, plus sign Analogue In
25 2
Mini-remote, seed sign Digital In
25 3 12 V
25 4
Mini-remote Ground
WS2 Port Pin Function Type
3 1
BioDrill Motor speed, input (RDC) Digital In
3 2
3 3
BioDrill Motor speed, input (RDC)
12 V
3 4
BioDrill Motor speed, input (RDC) Ground
4 1
Seed depth guard sensor, Autopilot Digital In
4 2
4 3
Seed depth guard sensor, Autopilot
12 V
4 4
Seed depth guard sensor, Autopilot Ground
12 1
12 2
BioDrill Motor speed, output (RDC)
PWM Out
12 3 12 V
12 4
BioDrill Motor speed, output (RDC) Ground
14 1
14 2
Autopilot, lift (RDC)
PWM Out
14 3 12 V
14 4
Autopilot, lift(RDC) Ground
15 1
15 2
Autopilot, lowering (RDC)
PWM Out
15 3 12 V
15 4
Autopilot, lowering (RDC) Ground
18 1
Tramline BioDrill Right (RDC) Digital In
18 2
Tramline BioDrill Right (RDC) Digital Out
18 3
Tramline BioDrill Right (RDC)
12 V
18 4
Tramline BioDrill Right (RDC) Ground
903099-en-gb; 19.01.2021 39
