Electrical system
19 1
Tramline BioDrill Left (RDC) Digital In
19 2
Tramline BioDrill Left (RDC) Digital Out
19 3
Tramline BioDrill Left (RDC)
12 V
19 4
Tramline BioDrill Left (RDC) Ground
20 1
Digital In
20 2
Following harrow, directional valve
PWM Out
20 3 12 V
20 4
Following harrow, directional valve Ground
21 1
Digital In
21 2
Following harrow, transport lock
PWM Out
21 3 12 V
21 4
Following harrow, transport lock Ground
22 1
Digital In
22 2
Autopilot, Open center valve
PWM Out
22 3 12 V
22 4
Autopilot, Open center valve Ground
23 1
Digital In
23 2
Following harrow, pressure control
PWM Out
23 3 12 V
23 4
Following harrow, pressure control Ground
