Appendix
28 Installation and maintenance instructions ecoFIT pure 0020230533_01
Appendix
A Overview of diagnostics codes
Note
Since the code table is used for various products, some codes may not be visible for the product in question.
Dia-
gnostics
code
Parameter
Values
Unit Increment, select, explanation
Default set-
ting
Own setting
Min. Max.
d.00 Heating maximum output – – kW The maximum heating output
varies depending on the product.
→ Section "Technical data"
Automatic: Unit automatically
adjusts the maximum output to
the current system demand
→ Section
"Technical
data"
Adjustable
d.01 Pump overrun in heating
mode
1 60 min 1 5 Adjustable
d.02 Maximum burner anti-
cycling time in heating
mode
2 60 min 1 20 Adjustable
d.04 Water temperature in the
cylinder
Current value ℃ – – Not
adjustable
d.05 Determined heating flow
set target temperature
Current value
℃ – – Not
adjustable
d.06 Hot water set target tem-
perature
Current value ℃ (Combination unit only) – Not
adjustable
d.07 Set target temperature
for the domestic hot wa-
ter cylinder
Current value ℃ – – Not
adjustable
d.08 Status of the 230 V ther-
mostat
Current value – 0 = Room thermostat open (no
heat requirement)
1 = Room thermostat closed
(heat requirement)
– Not
adjustable
d.09 Heating flow set target
temperature that is set
on the eBUS room ther-
mostat
Current value ℃ – – Not
adjustable
d.10 Status of the internal
pump in the heating cir-
cuit
Current value – off / on – Not
adjustable
d.11 Status of the heating
circuit's shunt pump
Current value – off / on – Not
adjustable
d.13 Status of the hot water
circuit's circulation pump
Current value – off / on – Not
adjustable
d.14 Operating mode of the
modulating pump
0 5 – 0 = variable rotational speed
(auto)
1; 2; 3; 4; 5 = Fixed rotational
speeds → Section "Setting the
pump output"
0 Adjustable
d.15 Pump speed Current value % – – Not
adjustable
d.16 Status of the 24 V room
thermostat
Current value – off = Heating off
on = Heating on
– Not
adjustable
d.17 Heating control – – – off = Flow temperature
on = Return temperature (ad-
justment for underfloor heating.
If you have activated the return
temperature control, the auto-
matic heating output determina-
tion function is not active.)
0 Adjustable
