Vaillant ecoFIT pure User Manual

Notes on the documentation 2
0020230532_02 ecoFIT pure Operating instructions 7
2 Notes on the
documentation
2.1 Observing other applicable
documents
▶ You must observe all operating instruc-
tions enclosed with the system compon-
ents.
2.2 Storing documents
▶ Keep this manual and all other applic-
able documents safe for future use.
2.3 Validity of the instructions
These instructions apply only to:
Product article number
Article
number
Gas Coun-
cil Number
VUW 256/6-3
(H-GB)
0010020389
47-044-68
VUW 306/6-3
(H-GB)
0010020390
47-044-74
VUW 356/6-3
(H-GB)
0010020391
47-044-70
3 Product description
3.1 Front view
1
2
1 Control elements 2 Plate with serial
number on the
rear
3.2 Control elements
50
1
2
3
1 Fault clearance
key
2 Operating but-
tons
3 Display
3.2.1 Operator control panel
50
1
9
8
7
6
2
3
4
1
5
1 Current heating
flow temperat-
ure, operating
mode, fault code
or additional in-
formation
2 Current assign-
ment of the right-
hand selection
button
3 Left- and right-
hand selection
buttons
4
and but-
ton
5 Fault clearance
key

Vaillant ecoFIT pure Specifications

General

Fuel Type	Natural Gas
Dimensions (H x W x D)	700 x 390 x 295 mm
ErP Rating	A
Mounting	Wall-mounted
Modulation	1:5
Type	Combination Boiler
Warranty	2 Years
Efficiency Rating	94%
