3 Product description
8 Operating instructions ecoFIT pure 0020230532_02
6 Maximum out-
put (only used
for Austria,
Germany and
Switzerland)
7 Access to the
menu for addi-
tional information
8 Current assign-
ment of the left-
hand selection
button
9 Active operating
status
3.3 Displayed symbols
Sym-
bol
Meaning Explanation
Burner operating
correctly
Burner on
bar
Current filling
pressure of the
heating system
The dashed lines
show the permit-
ted range
– Permanently
on: Filling
pressure in
the permitted
range
– Flashing:
Filling pres-
sure outside
the permitted
range
Hot water gener-
ation active
– Permanently
on: Draw-off
mode before
burner is on
– Flashing:
Burner on in
draw-off mode
Heating mode
active
– Permanently
on: Heating
mode heat
requirement
– Flashing:
Burner on in
heating mode
Comfort mode
active
– Permanently
on: Comfort
mode active
– Flashing:
Comfort mode
active, burner
on
Maintenance re-
quired
Information on
the maintenance
message in the
"Live Monitor"
Sym-
bol
Meaning Explanation
Summer mode
active
Heating mode is
switched off
Burner anti-cyc-
ling time is active
To avoid the
need for frequent
switching on and
off (increases the
product's working
life).
F. X X
Fault in the
product
Appears instead
of the basic
display, may be
an explanatory
plain text display.
3.4 Information on the
identification plate
The identification plate is mounted on the
underside of the product in the factory.
The identification plate keeps record of
the country in which the product is to be
installed.
Information
on the identi-
fication plate
Meaning
Barcode with serial number
Serial number For quality control purposes;
3rd and 4th digits = year of
production
For quality control purposes;
5th and 6th digits = week of
production
For identification purposes;
7th to 16th digits = product
article number
For quality control purposes;
17th to 20th digits = place of
manufacture
ecoFIT pure Product designation
2H, G20
– 2 kPa
(20 mbar)
Factory setting for type of
gas and gas connection
pressure
Cat. Unit category

Vaillant ecoFIT pure Specifications

General

Fuel Type	Natural Gas
Dimensions (H x W x D)	700 x 390 x 295 mm
ErP Rating	A
Mounting	Wall-mounted
Modulation	1:5
Type	Combination Boiler
Warranty	2 Years
Efficiency Rating	94%
