General requirements 3
Instructions for installation and servicing ecoMAX 11
3.3 Contents included with boiler (ecoMAX 800/2)
Ensure that all contents are included before commen-
cing installation.
Fig. 3.1 Items supplied with unit (ecoMAX 800)
DO NOT remove the boiler from the polystyrene base at
this stage.
Item Quantity Description
1 1 Boiler
2 1 Hanging bracket
3 3 Installation and Servicing, Users and
Flue Installation Instructions
4 1 Installation and connection accessories
5 2 Guarantee Card and Benchmark log book
6 1 Template
7 4 Copper tails for gas and water pipework
8 3 Flow and return service valve, gas service
valve
9 1 Pressure relief valve/double check valve
10 1 Lower cover (packed inside boiler)
Table 3.1 Items supplied with unit (ecoMAX 800)
3.4 Contents included with boiler (ecoMAX 600/2)
Ensure that all contents are included before commen-
cing installation.
Fig. 3.2 Items supplied with unit (ecoMAX 600)
DO NOT remove the boiler from the polystyrene base at
this stage.
Item Quantity Description
1 1 Boiler
2 1 Hanging bracket
3 3 Installation and Servicing, Users and
Flue Installation Instructions
4 1 Installation and connection accessories
5 2 Guarantee Card and Benchmark log book
6 1 Template
7 4 Copper tails for gas and water pipework
8 3 Flow and return service valve, gas service
valve
9 1 Pressure relief valve
10 1 Lower cover (packed inside boiler)
Table 3.2 Items supplied with unit (ecoMAX 600)
4
5
2
6
7
3 1
10
9
10
9
1
4
5
2
6
7
8
3
