0020308120_02 Air/flue pipe installation manual 9
Optional connection accessories Article number A B, C D, E
Extension for external wall pipe bracket (stainless steel), 90–280 mm 0020042752 X
Extension (stainless steel), concentric, 0.5 m 0020042753 X
Extension (stainless steel), concentric, 1.0 m 0020042754 X
Extension that can be shortened (stainless steel), concentric, 0.5 m 0020042755 X
Elbow (stainless steel), concentric, 87° 0020042756 X
Elbows (stainless steel), concentric (2 pcs), 45° 0020042757 X
Elbows (stainless steel), concentric (2 pcs), 30° 0020042758 X
Inspection piece (stainless steel), 0.25 m, concentric 0020042759 X
Rain penetration collar (stainless steel) for roof penetration 0020042760 X
1 In accordance with the construction regulation, installation on the external wall in buildings higher than 18 m is permitted

Vaillant ecoTEC plus 615 Specifications

General

Model	ecoTEC plus 615
Category	Boiler
Output	15 kW
Dimensions (H x W x D)	720 x 440 x 338 mm
Fuel Type	Natural Gas
Mounting	Wall-mounted
Max. Working Pressure	3 bar
NOx Emissions Class	5
Flue Options	Horizontal and Vertical
Heating Flow Temperature Range	30°C to 80°C
Efficiency	94% ErP
