9Operating instructions ecoTEC plus 937
4.3 Start-up
bar
iFP
1
2
Fig. 4.5 Switching the appliance on
Use the main switch (1) to switch the appliance on and
off:
I: "ON
0: “OFF”
When you switch the unit on the display (2) shows the
current heating feed temperature.
To adjust the appliance according to your requirements,
read sections 4.4, and 4.6, which describe the setting
options for hot water supply and heating.
a
Caution!
Risk of damage!
The frost protection and monitoring systems
are only active when the main switch of the
appliance is in the "I” position and it is not
disconnected from the mains power supply.
To ensure that these protection devices remain active,
switch your gas wall boiler on and off using the
controller (see the corresponding operating manual).
Section 4.9 describes how to put your gas wall boiler out
of operation.
4.4 Domestic hot water operation
The boiler can only be used if the heating system has
water in it (see Section 4.2.2).
4.4.1 Setting the hot water temperature
bar
iFP
2
1
Fig. 4.6 Setting the water temperature
Switch on the appliance as described in section 4.3.
Turn the knob (1) for setting the hot water
temperature to the temperature you require.
In order to increase the temperature turn the knob in
a clockwise direction, and to reduce the temperature
turn the knob in an anticlockwise direction. In doing
this:
- left-hand stop approx. 35 °C
- right-hand stop max. 65 °C
h
Note
This knob is used to set the maximum hot
water temperature. If turning the knob all the
way to the right has no effect on the
temperature then the hot water preparation
system is running at full output for the selected
throughput.
The set value is shown in the display during the setting
process (2).
After approx. 3 seconds the display returns to standard
mode (the current heating flow temperature).
a
Caution!
If you live in an area with hard water, please do
not turn the knob (1) further than the mid-
position (12 o'clock position) to prevent
excessive scale build up.
Operation 4
