Vaillant ecoTEC plus VUW 6/5-5 Series - Page 14

14 Installation and maintenance instructions 0020244997_07
Technical data – Electrics
VU 126/5-
5 (H-GB)
ecoTEC plus
612
VU 156/5-
5 (H-GB)
ecoTEC plus
615
VU 186/5-
5 (H-GB)
ecoTEC plus
618
VU 186/5-
5 (P-GB)
ecoTEC plus
618
VU 246/5-
5 (H-GB)
ecoTEC plus
624
VU 306/5-
5 (H-GB)
ecoTEC plus
630
Electric connection
230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz
Permissible connected
voltage
190 to 253 V 190 to 253 V 190 to 253 V 190 to 253 V 190 to 253 V 190 to 253 V
Built-in fuse (slow-blow)
2 A 2 A 2 A 2 A 2 A 2 A
Min. electrical power con-
sumption
35 W 35 W 35 W 35 W 35 W 45 W
Max. electrical power
consumption
55 W 60 W 65 W 65 W 70 W 90 W
Electrical power con-
sumption, standby
< 2 W < 2 W < 2 W < 2 W < 2 W < 2 W
Level of protection
IP X4 D IP X4 D IP X4 D IP X4 D IP X4 D IP X4 D
VU 306/5-
5 (P-GB)
ecoTEC plus
630
VU 386/5-
5 (H-GB)
ecoTEC plus
637
VUW 196/5-
5 (H-GB)
ecoTEC plus
825
VUW 246/5-
5 (H-GB)
ecoTEC plus
832
VUW 246/5-
5 (P-GB)
ecoTEC plus
832
VUW 306/5-
5 (H-GB)
ecoTEC plus
835
Electric connection
230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz
Permissible connected
voltage
190 to 253 V 190 to 253 V 190 to 253 V 190 to 253 V 190 to 253 V 190 to 253 V
Built-in fuse (slow-blow)
2 A 2 A 2 A 2 A 2 A 2 A
Min. electrical power con-
sumption
45 W 55 W 35 W 35 W 35 W 45 W
Max. electrical power
consumption
80 W 95 W 80 W 85 W 85 W 90 W
Electrical power con-
sumption, standby
< 2 W < 3 W < 2 W < 2 W < 2 W < 2 W
Level of protection
IP X4 D IP X4 D IP X4 D IP X4 D IP X4 D IP X4 D
VUW 286/5-
5 (H-GB)
ecoTEC plus
838
Electric connection
230 V/50 Hz
Permissible connected
voltage
190 to 253 V
Built-in fuse (slow-blow)
2 A
Min. electrical power con-
sumption
55 W
Max. electrical power
consumption
120 W
Electrical power con-
sumption, standby
< 3 W
Level of protection
IP X4 D
