Table 6 Vane Specifications
Property Description/Value
Sensor / Transducer type Potentiometer
Measuring range
WMS302
WMS301
0 ... 360°
0 ... 355°
Starting threshold < 1.0 m/s
Damping ratio 0.3
Overshoot ratio 0.4
Delay distance 0.6 m
Accuracy
Better than ± 3°
Table 7 Common Specifications
Property Description/Value
Supply voltage 3 ... 15 VDC
Electrical connections 5-pin male with 12 mm
threads
Body material AlMgSi, gray anodized
Cup material PA, reinforced with carbon
fiber; black
Vane material PA, reinforced with glass fiber,
white
Operating temperature - 40 ... + 55 °C (-40 ... +131°F)
Storage temperature - 60 ... + 65 °C (-76 ... +149°F)
Dimensions 265 (h) × 360 (w) mm
(10.4 (h) × 14.2 (w) in)
Weight 360 g (12.7 oz)
