Valeo TM08 User Manual

-23-
Current
Compressor
is kept
Compressor
is replaced
Factory
oil
charge
Amount
recovered
Charging
amount
Amount
to remove
from new
compressor
TM08
TM13
TM15
9.2
5.5
or more
Same as
recovered
3.7
Under
5.5
5.5 2.7
TM16 11.0
6.6
or more
Same as
recovered
4.4
Under
6.6
6.6 3.3
Current
Compressor
is kept
Compressor
is replaced
Factory
oil
charge
Amount
recovered
Charging
amount
Amount
to remove
from new
compressor
TM08
TM13
TM15
150
90
or more
Same as
recovered
60
under
90
90 45
TM16 180
108
or more
Same as
recovered
72
Under
108
108 54
3-Handling instructions
unit: cm
3
& cc
CAUTION!
The specified oil quantity differs, depending
on the type of air conditioner system. A
label describing the specified quantity is
attached to the compressor.
Additionally, all of the oil cannot be removed
when draining the compressor as some
remains as an oil film on the inside of the
compressor and the system components.
Therefore, refer to the table at left when
recharging the compressor with oil. Excess
oil adversely affects the cooling capacity
and the compressor.
6. Install the oil filler plug and tighten it to the
specified torque.
Specified torque: 13 ~ 15 N·m
{1.3 ~ 1.5 kgf·m, 9.4 ~ 10.2 lbf·ft}
Replacement of components
When replacing the system’s component parts,
supply the following amount of oil to the com-
pressor.
Component mounted Amount of oil
Evaporator 50 cm
3
(3 cu in)
Condenser 30 cm
3
(1.8 cu in)
Receiver drier 10 cm
3
(0.6 cu in)
After installing these component parts, check
the compressor oil. Refer to page 22.
CAUTION!
The oil filler plug O-ring must be replaced
with a new one.
unit: cu in
50cm
3
(3 cu in)
10cm
3
(0.6 cu in)
30cm
3
(1.8cu in)
