Valeo TM55 - Page 44

- 42 -
8- Service tools
110
40
25
70Ø
51
-0.1
Ø
58
+0.2
Ø
82.6
-0.1
Ø
5
Spacer
Part Name
3rd Angle Proj.
HQ-HTL
HRC58
SK3
Heat Treatment
& Hardness
Surface Treatment
Material
Unless otherwise specified,
the edges to be slight chamfering.
Should remove burrs and fluff.
Br
Pulley Installer Assy
2
A
A
Section view A-A
18Ø
28.5
±0.2
Ø
0.5C
0.5C
2C
5C
27.7( )
24
-0.3520 15
28
-0.3
Ø
Collar
Part Name
3rd Angle Proj.
HQ-HQf
HRC40 to 45
S45C
Heat Treatment
& Hardness
Surface Treatment
Material
Unless otherwise specified,
the edges to be slight chamfering.
Should remove burrs and fluff.
Br
Pulley Installer Assy
3
M16x2.0
