Valeo TM55 - Page 43

- 41 -
8- Service tools
Material
Bolt
Spacer
Collar
Part Name
Material
Heat Treatment
& Hardness
Surface Treatment
3rd Angle Proj.
Assy
1
2
3
1
2
3
Pulley Installer Assy
1510015246
12Ø
54
12
-0.25
13.9( )
Bolt
Part Name
3rd Angle Proj.
HQ-HQf
HRC40 to 45
S45C
Heat Treatment
& Hardness
Surface Treatment
Material
Unless otherwise specified,
the edges to be slight chamfering.
Should remove burrs and fluff.
Br
Pulley Installer Assy
1
M16x2.0
M10x1.25
6Ø
2C
1C
