Electrical
7 Electrical
Power GND and Signal GND are isolated.
7.1 Power - miniIPS 2
7 28V DC input (isolated)
Draws approximately 25mA at 12V DC
7.2 Power - miniIPS 2e
7 28V DC input (isolated)
Draws approximately 125mA at 12V DC
7.3 Wiring Information
A miniIPS2 systems are supplied with a short (50cm) lead for splicing or testing and a USB\Power cable for
interface to a PC for setup.
7.3.1 Serial Connection
6 Way Male SubConn (MCIL6M)
PIN
FUNCTION
1
RS232 GND
2
RS232 Tx (Out of sensor) or RS485A
3
RS232 Rx (Into sensor) or RS485B
4
+V
5
Link to Pin 1 for RS485
Not Connected for RS232
6
Power GND
7.3.2 Ethernet Connection
Contact Valeport for replacement cable
