Valet 551T - Wiring Harness Diagrams; Primary Harness (H1) Diagram; 5-Pin Ribbon Harness Diagram; Heavy Gauge Relay Satellite Diagram

primary harness (H1) wiring diagram
______
______
______
______
______
______
______
______
remote start ribbon harness wiring diagram
______
______
______
______
______
heavy gauge relay satellite wiring diagram
______
______
______
______
______
______
PINK/WHITE (+) OUTPUT TO SECOND IGNITION CIRCUIT
PURPLE (+) OUTPUT TO STARTER CIRCUIT
ORANGE (+) OUTPUT TO ACCESSORY CIRCUIT
PINK (+) OUTPUT TO IGNITION CIRCUIT
RED (+) HIGH CURRENT 12V INPUT
RED (+) HIGH CURRENT 12V INPUT
1
2
3
4
5
6
PURPLE (-) 200 mA STARTER RELAY TURN-ON
ORANGE (-) 200 mA ACCESSORY RELAY TURN-ON
PINK (-) 200 mA IGNITION RELAY TURN-ON
YELLOW (+) IGNITION INPUT TO REMOTE START
RED (+) CONSTANT POWER
1
2
3
4
5
NO WIRE
NO WIRE
GRAY/BLACK (-) WAIT-TO-START INPUT
WHITE (-) LIGHT FLASH OUTPUT
YELLOW (+) IGNITION (OUTPUT TO SECURITY SYSTEM)
LIGHT GREEN/BLACK (-) FACTORY DISARM/SPECIAL ACCESSORY
WHITE/BLUE (-) ACTIVATION INPUT
BLACK (-) CHASSIS GROUND INPUT
H1/1
H1/2
H1/3
H1/4
H1/5
H1/6
H1/7
H1/8
10 © 2000 Directed Electronics, Inc.
