11
©
2005
Directed Electronics, Inc.
System Features Menus
NNoottee::
Factory default settings are shown in
BBOOLLDD
.
NNoottee::
For feature number 1-4, the 3.5 second door lock pulse
setting the siren chirps twice, for the 0.4 second door lock
pulse setting the siren chirps three times.
Feature Descriptions
The features of the system are described below.
1 IGNITION CONTROLLED DOOR LOCK ON/OFF:
When turned on, the doors will lock
three seconds after the ignition is turned on.
2
IGNITION CONTROLLED DOOR UNLOCK ON/OFF:
When turned on, the doors will
unlock when the ignition is turned off.
3 IGNITION CONTROLLED DOMELIGHT:
If turned on, the system will turn on the
domelight for 30 seconds when the ignition is turned off. The domelight supervision output (H1/4)
wire must be connected to an optional relay as described in the Primary Harness Wire Connection
Guide.
4 DOOR LOCK PULSE DURATION:
Some European vehicles, such as Mercedes-Benz and
Audi, require longer lock and unlock pulses to operate the vacuum pump. Programming the system
to provide 3.5 second pulses will accommodate the door lock interface in these vehicles. The default
Feature Default LED ON Setting LED OFF Setting
Number (Press Channel 1) (Press Channel 2)
1 Ignition-controlled door lock ON Ignition-controlled door lock OFF
2 Ignition-controlled door unlock ON Ignition-controlled door unlock OFF
3 Ignition-controlled domelight ON Ignition-controlled domelight OFF
4 0.8 second door lock pulses 3.5 second door lock pulses/0.4 sec.
5 Double pulse unlock OFF Double pulse unlock ON
6 Double pulse lock OFF Double pulse lock ON
7 Comfort closure OFF Comfort closure ON
8 Code Hopping ON Code Hopping OFF
