Machine Angles (continued)
22. Press
ENTER
to select the 1/0 column. 1/0 is used
to override sequences in the list on (1) or off (0).
See Figure 27-1.
• Press
1
to turn ON.
• Press
2
to turn OFF.
23. Press
ENTER
with cursor located in the SOL#
column to toggle solenoids. See Figure 27-2.
• Press number to toggle Solenoids that are ON
(1-9). Solonoids shown are ON.
24. Press
ENTER
with cursor located in the TEN+ col-
umn to toggle solenoids. See Figure 27-3.
• Press number to toggle Solenoids displayed
(10-16). Solenoids shown are ON.
25. Press
ESC
to leave this menu, if any changes
have occurred the new table will be saved to the
STB. See Figure 27-4.
Retracted Psi
This menu is only functional when pressure regulators
are not selected. See Figure 27-5.
26. Press
PROGRAMS
and
3
to display the retracted
psi screen. See Figure 27-6.
• Press
1
to use current psi setting.
• Press
2
to set psi setting manually. Min. 5 psi
to Max. 150 psi.
• Press
ENTER
to confirm entered data.
27. Press
0
or
ESC
to leave this menu.
MSTART END 1/0 SOL# TEN+
136.5 138.2 1 123456 1
140. 145.2 1 1234567 12
PRESS 1 . . ON 2 . . OFF >
Figure 27-1
MSTART END 1/0 SOL# TEN+
136.5 138.2 1 123456 1
140. 145.2 1 1234567 12
PRESS NUMBER TO TOGGLE >
Figure 27-2
MSTART END 1/0 SOL# TEN+
136.5 138.2 1 123456 1
140. 145.2 1 1234567 12
PRESS NUMBER TO TOGGLE >
Figure 27-3
WRITING TABLE TO SMART TOWER BOARD
(RETRYING)
100%
Figure 27-4
0 EXIT
1 USE CURRENT 30 PSI
2 SET MANUAL
PRESS NUMBER >
Figure 27-5
0 EXIT
1 USE CURRENT 30 PSI
2 SET MANUAL
SELECT PRESSURE (30) >
Figure 27-6
