Diagnostics
Error Code Summary
A list of possible error codes appears below in Figure 30-1. See the Troubleshooting section for possible causes
and corrective actions. Refer to Error Codes on page 36 for corrective actions.
E01 – BATTERY BACKED RAM – CHECKSUM
FAILED AT POWER UP
A BBRAM memory error has occurred in the Control Panel
Module.
E02 – EEPROM – CHECKSUM FAILED AT
POWER UP
A EEPROM memory error has occurred in the Control
Panel Module.
E03 – UNIT RESETS – THIS IS LOGGED WHEN
THE SOFTWARE RESETS
The machine has reset for some reason.
E04 – KEYPAD – POSSIBLE KEY STUCK,
CHECK KEYPAD CONNECTION
A key on the keypad is stuck and has been sending a
continuous signal to the machine for at least 10 minutes.
E06 – STB COMMUNICATIONS STB communications error.
E11 – STB FLASH – CHECKSUM FAILED AT
POWER UP
The flash memory in the STB is corrupt.
E12 – STB EEPROM – CHECKSUM FAILED AT
POWER UP
EEPROM memory in the STB is corrupt.
E13 – STB UNIT RESETS – THIS IS LOGGED
WHEN THE SOFTWARE RESETS
STB reset unexpectedly, there are a number of possible
causes for this error.
E15 – STB SOFTWARE ERROR – STB AND VCS
SOFTWARE VERSION ARE NOT COMPATIBLE
Software that is running on the panel module and the
STB are not compatible.
E16 – STB SENSOR REFERENCE ERROR The 5 VDC that supplies power to the system sensors in
out of tolerance.
E17 – STB GPS ERROR – CHECK STB AND
GPS CABLE CONNECTIONS
No data coming from the GPS receiver or GPS guidance
system.
E18 – STB PRESSURE ERROR – PRESSURE
SENSOR READING IS OUT OF RANGE
The pressure transducer input for the system is outside
normal operating limits.
E19 – STB ANGLE ERROR – PRESSURE
ANGLE SENSOR READING IS OUT OF RANGE
Angle sensor input for the system is outside its normal
operating limits.
E20 – OVERRIDE TABLE – CHECKSUM FAILED
AT POWER UP
The storage are that contains the override tables is
corrupt.
Figure 30-1
