11
*
The water consumption in cylinder depends on:
the incoming water temperature,
the ice cream mixture (type),
the ice cream mixture temperature,
the required final ice cream temperature.
3 TRANSPORTATION AND PLACING OF THE
APPLIANCE
3.1 INSTRUCTIONS FOR PREVENTING INJURIES
Pay due attention to legally required safety measures.
At work wear suitable clothing. Do not wear ties, jeweller’s chains or belts,
which could get caught in the machine.
Do not shift or dislocate the safety switches or protective parts.
Make sure that the lifting device is in good condition and that its load capacity
exceeds the weight of the appliance (refer to the technical specifications data
sheet).
Lift the appliance following the instructions for its use and maintenance. Pay
attention to the handling and handgrip locations. The use of a suitable lifting
device is recommended.
While lifting or moving the appliance do not stand under the machine.
Do not turn the appliance after holding the cables or the water hose has lifted it.
If you have to attend to any work higher up above the appliance, you should use
a suitable ladder and not the appliance for support.
SNOWY
T
DIMENSION (mm) POWER
cca
ICE-CREAM
VOLUME/CYCLE
Kg Width
Depth Height
KW * l/ciklus Kg/h Min kg Max kg
5 TTi 512 721+241 1454 4,6 14 7/36 1 5
7 TTi 512 721+241 1454 7,6 17 9/45 1,5 7,5
12 TTi 512 721+241 1454 10,9 21 12/75 2 12,5
16 TTi 610 839+241 1454 15,3 24 18/100 3 16,5
27 TTi 610 949+241 1454 17,5 ? 24-162 5 27
