60
12.2 BASIC RULES FOR OPERATING THE APPLIANCE
The user operates the appliance standing in front of appliance. The appliance
must be always under users control during operation. Only a single operator
can use the appliance at the time.
The simultaneously use of the appliance from multiple users is forbidden.
12.3 PROCESSING CYLINDER DOOR
Lifting the handle over the taper and shifting it to the right release the
processing cylinder door. The door can now be opened.
ECCENTRIC ARM LOCK
STOP SWITCH
EJECT HOLE COVER LOCKING SCREW
HINGES
WATER PIPE
WATER VALVE
CYLINDER DOOR
