SHUTTLE LEVER (Twin---Trac), fitting instruction
6000---8750 69.415.11.1997
1(4)
25.09.1997
Shuttle l ever (Twin Trac) 33494400.........
--- Remove the RH side rear wheel, mudguard ser-
vice cover and ventilation filter with its pipe. Dis-
connect and turn to one side hydraulic hoses.
Plug the hoses and nipples. Remove t he lever
console s ide panel, upper panel, remove the AC/
ACD control unit rubber band and the relay
fastening bracket.
--- Measure positions of protective rubber 6 and
screw holes, see picture A
.1.
--- Measure and make hole onto the cab panel, see
picture B.
--- Measure fastening holes for fastener 1 onto the
cab wall on the RH mudguard side.
Try to make an accurate measurement. Use the
fastener as a pattern. Drill four ø 8 holes, see
drawing A. NOTE! Be careful not to damage the
wires when drilling.
--- Fit lever 10 onto the fastener 1,placewasher 13
and nut 14 (without play). Turn the lever straight.
--- Try the fastener w ith the lever and an intermedi-
ate rubber piece. Check that the lever is in the
middle of the hole. If not, loosen and adjust the
lever.
--- Fit the fastener together w ith the lever and pro-
tective rubber 6 (the intermediate piece 5 is fitted
between the cab wall and the fastener) with screw
2,washer3 and lock nut 4.
The protective rubber is fitted from under with
screw 8,washer7 and lock nut 9.
--- Fit the lever knob 20 together with push buttons
(the button with red wire is fitted against the mud-
guard) onto the lever 10 with screws 21, and nut
22. Pull the wires t hrough the lever tube. Fit the
protective plastic and the round connector 32.
The yellow wires
(2 pcs) are connected together to
the round connector.
Fit t he connector housing 30
(the wires are con-
nected to the corr.coloured wires of connector 29,except
that the green wire corr. to the connector 29 brown wire).
Fit the cover on t he knob.
--- Remove the existing shuttle lever.
Weld the lever extension 19 to the removed
shuttle lever, see drawing C. Refit the lever.
---Fitthejointbar18 and adjust the gear lever. Lock
with the nut.
--- Ma k e ø 12, 5 h ole f or le ad --- in r u b be r 33 through
the front panel, see drawing D.
Fit the lead---in rubber and draw wire loom 25
through it.
