SHUTTLE LEVER (Twin---Trac), fitting instruction
6000---8750 69.415.11.1997
2(4)
25.09.1997
--- Fit the round connector 32 onto red, yellow and
blue wires.
Put the w ires with the round connector into the
connector housing 33 and connect it to con-
nector housing ”X23”.
--- HiShift: Disconnect the black and green wires of
the foremost shuttle lever from connector ”S45”.
Connect black and brown wires of the wire loom
to corr. coloured wires of the foremost shuttle
lever to the connector with aid of the round con-
nector 32.
--- Ti e t h e w ir es .
--- Check the electrical functions.
--- Adjust the relay bracket according to drawing E.
--- Turn the ventilation filter backw ards (turn the T---
union). Clearance must be left on the cab side.
Refit the hydraulic hoses.
--- Grease the gear lever.
Check that the gear lever and the joint bar can
move freely.
--- R e fi t a l l removed pa r t s .
1 33494400 Suunnanvaihtovipu Fram---backspak Forward---reverse gear lever Twin---Trac
1 1 70157100 .Kiinnitin Fäste Support
2 4 .Ruuvi Skruv Screw M8x25
3 4 .Aluslaatta Bricka Washer 8x19x1,5
4 4 .Lukitusmutteri Låsmutter Locking nut M8
5 1 70157500 .Kumivälipala Gummimellanlägg Rubber
6 1 612880 .Suojakumi Damask Rubber shield
7 2 960139 .Aluslaatta Bricka Washer
8 2 955272 .Ruuvi Skruv Screw M6x19
9 2 .Lukitusmutteri Låsmutter Locking nut M6
10 1 70157200 .Vaihdevipu Växelspak Gear lever
11 2 30208600 .Holkki (musta) Bussning (svart) Bushing (black)
12 1 GG0088 .Vo idenippa Smörjnippel Greasing nipple
13 1 29869 .Aluslaatta Bricka Washer 16,5x38x6
14 1 963121 .Lukitusmutteri Låsmutter M16x1,5
15 2 959081 .Kulmakuulanivel Vinkelkulled Angle joint
16 2 971083 .Lukitusmutteri Låsmutter Locking nut M10
17 2 .Mutteri Mutter Nut M10
18 1 70157300 .Niveltanko Länkstång Joint rod
19 1 70157400 .Pidennyskappale Hävarmsförlängare Lengthening piece
20 1 33319500 .Vivun nuppi Spakknopp Knob
21 2 HE6984 .Ruuvi Skruv Screw M5
22 2 JB1105 .Mutteri Mutter Nut M5
23 1 .Suojakansi Skyddslo ck Lock
24 2 948210 .Johdinside Buntband Band
25 1 .Johdinsarja Kabelknippe Wiring harness
26 1 33269700 .Johdin Kabel Wire
27 1 32908300 .Nappi Knopp Button
28 1 32948400 .Painonapit Tryckknappar Button
29 1 SA1775 .Liitinkotelo Skarvhus Connector housing
--- 5 SA1785 .Liitin Anslutning Pin
30 1 SA1774 .Liitinkotelo Skarvhus Connector housing
32 10 SA1776 .Liitin Anslutning Pin
33 1 SA1787 .Liitinkotelo Skarvhus Connector housing
34 1 32643500 .Läpivientikumi Skyddsbussning Rubber
35 1 .Suojaputki Skyddshölje Shield
