1113
Model
Code Page
1(3)6000---8400 79
WAT ER RESERV OIR, FITTING INSTRUCTION
26.09.1994
04.06.1993
Water reservo ir (+pump) 32837200
The water reservoir capacity is 85 litres. The reservoir
material is stainless steel. The reservoir has a pump
with output of 7,3 l/min at a pressure of 2,5 kp/cm
2
.
The water hose is fitted on a portable hose drum and
thehoselengthis20 m.
The water tank can be used as a fire---fighting equip-
ment e.g. when working in the peat industry
NOTE! In a cold season the tank should be drained
(or anti---freeze agent should be used). Pour into the
empty tank engine coolant and let the pump run for a
while so that all water in the pump runs out.
Never use the pump without liquid
.
The pump has been connected to the fuse F14 (per-
manent current).
FITTING:
--- Remove the foot step irons.
--- Fasten padding band 2 onto the water tank and
also band 3 (7 pcs) onto the frame 4.
--- Unscrew the nut of the lower stud boltM16 and the
upper hexagonal socket screw M12 on the LH side
in the bolted joint between gearbox---fuel tank.
Fasten the support 31 with these nut and screw.
Place the frame 4 temporarily into place. Estimate
the position of the cut---off point of the footstep RH
side support iron. Mark places for the fixing holes
(ø18 mm) on the footstep iron and drill the holes.
--- Fit the stand and the tank. NOTE! Guidee.g. with
a
flat iron the edge seal of the intermediate
frame
protective shield so that it stays between the
tank
and the intermediate frame.
Connect hoses 18 and 9 to the tank.
--- Connect the other end of hose 18 to the filling pipe
20. Use the filling pipe as a pattern (donot bendthe
hose) a nd drill holes (2 pcs, ø13 mm) into the inner
surface of the LH side mudguard. Fasten the filling
pipe.
--- Place t he hose stand 22 on the RH side mudguard
and mark places for holes (2 pcs, ø 9 mm) (if you
want that the side window can be opened, the
stand should be fitted partly on the console of the
rear light).
Drill holes and fasten the stand.
--- If the tractor has an air conditioner and its hoses
have been drawn behind the cab front attachment,
the hoses should be moved to the front side of the
attachment.
In this case, unscrew the cab front attaching bolts
and slacken the cab rear bolts. Also the PTO con-
trolcable should be detached. Raise the cab about
50 mm and move the hoses to the front side of the
attachment. (Note! Remove out from way t he
attaching screws of the engine heater sock et).
Also detach the drier and push excess hose length
into the engine compartment.
