121.03.2000 6000---8950
39.7
MAIN CURRENT SWITCH, fitting instruction 16.08.1993
(4)
Main current switch (battery crosswise
x
) 32599000.
M. current sw.,
LH (battery lengthwise
xx
) 32599010.
M. current switch,
RH (4---cyl, 6200---6800,
6250Hi---6850Hi)
32599020......................
M. current switch
RH (G24514--->,6---cyl) 33348700
x
) 6800: ---F03311, 50---series:---F10105, 6000---8400:
---F17108, xx) : ---G24513
With aid of the main switch, current to all tractor
can be switched off (except the fuse F2---> radio,
speedometer) e.g. when you leave the tractor.
This prevents possible fire risk caused by short
circuits in the electic system.
The switch lever can be removed, if needed.
FITTING:
--- Remove the engine hood side plates. Discon-
nect the battery earth lead.
--- 32599000: Fit the fastener 2 to the holes on the
battery holder (drill holes if needed). Fasten the
main current switch 6 (note the nut caps 8).
--- Disconnect the starter motor +lead and push
protective tube 1 onto the cable. Connect the
lead to the main switch. Connect the lead 5 to
the starter motor and to the main switch. Check
that the leads do not rub the other tractor parts.
Connect the battery earth lead.
---Drilla ø37mmholethroughthesideplate(see
fig.), if not made earlier. Paint the hole edges.
Fasten the switch lever strap 9 under the nut of
the side plate attachment. Fasten the sticker 7
(see fig.).
--- 32599010: Fit the fastener 2A to the holes on
the battery holder. Fasten the main current
switch 6.
--- Disconnect the starter motor +lead and connect
the lead to the main switch. Connect the lead 5
to the starter motor and to the main switch.
Check that the leads do not rub the other tractor
parts. Connect the battery earth lead.
---Drilla ø37mmholethroughthesideplate(see
fig.), if not made earlier. Paint the hole edges.
Fasten the switch lever strap 9 under the nut of
the side plate attachment (6---cyl. + visco: drill a
hole 7mm) Fasten the sticker 7 (see fig.).
--- 32599020: Fit the fastener 2 under the engine
fastening screws (tightening torque 90Nm, M10).
Fasten the main current switch 7 (+ strap 9).
--- Disconnect the starter motor +lead and connect
the lead to the main switch. Connect the lead 6
to the starter motor and to the main switch.
Check that the leads do not rub the other tractor
parts. Connect the battery earth lead.
--- Fasten the sticker 5 (see fig.).
