Powered front axle
964
Model Code Page
64. Powered front axle
8. 11. 1990
6000--8750 640 4
1
2
3
4
Figure 1. Powered front axle
1. 4WD switch is placed on the range gear lever knob
2. Solenoid valve for 4WD on the servo valve block
3. 4WD clutch/output sha ft is fitted i n the l ower pa rt of the reverse shuttle housing
4. Propeller shaft
Note! Reconditioning 4WD clutch, see section 44
Note! 4WD engages automatically when the brake pedal/pedals are depressed
