Van Norman 204 - Component and Control Identification

204 Heavy Duty Combination Brake Lathe
COMPONENT/CONTROL IDENTIFICATION AND FUNCTION
1. Spindle Stop
2. Handwheel for Spindle Position
3. Oil Fill (Oil Daily #30)
4. On/Off/Light Switch
5. Oil Fill & Breather
6. Spindle Arbor
7. Tool Bar (for Drum Turning) – 204S
8. Tool Holder Turret
9. Handle wheel to position Tool Bit for Drum Turning –204S
10. Chip Tray
11.Tool Storage Area
12.Speed Control Handle
13.Speed Lock Knob
14. Drain Plug
4
3
2
1
13
12
5
6
7
8
9
10
11
