Vanner VTS12-1500 - Mechanical Drawings

VANNER Incorporated Owner’s Manual
VTS Series 1500Watt 6 True Sine Wave Inverter/AC transfer Switch
2-4. Mechanical Drawings
AC INPUT
BREAKER
S S S S
0
1
PWR. SAV. FREQ.
1 2 3 4
POWER STATUS
INPUT LEVEL
LOAD LEVEL
PORT
REMOTE
GND
ENB ENB
POWER
ON-OFF-REMOTE
DC INPUT
POS(+)NEG(-)
REVERSE POLARITY
WILL DAMAGE UNIT
