Vapac LE05 - LExxP Unit Electrical Demand Loads (LE45 P-LE90 P)

18
Model Ref.
LE45P
Cylinder 1 1 1 1 1 1
Nominal Output Kg/hr 45 45 45 45 45 45
Nominal Output lb/hr NA NA 99 99 99 99
Voltage V 200 230 380 400 415 440
Power input rating Kw NA NA 33.79 33.85 33.93 33.45
Electrical Supply Ph's NA NA 3Ph 3Ph 3Ph 3Ph
No. of electrodes NA NA 6 6 6 6
Full load Current A NA NA 62 59 57 53
Maximum overcurrent A NA NA 68.2 64.9 62.7 58.3
Fuse Rating/phase A NA NA 80 80 80 80
Supply cable terminals mm
2
NA NA 35 35 35 35
Wiring diagram A4-LZD-561
Cabinet size 2
Model Ref.
LE60P
Cylinder 1 2 1 2 1 2 1 2 1 2 1 2
Nominal Output Kg/hr 30 30 30 30 30 30 30 30 30 30 30 30
Nominal Output lb/hr 66 66 66 66 66 66 66 66 66 66 66 66
Voltage V 200 200 230 230 380 380 400 400 415 415 440 440
Power input rating Kw 22.38 22.43 22.43 22.38 22.35 22.25 22.38 22.43 22.32 22.25 22.41 22.5
Electrical Supply Ph's 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph
No. of electrodes 6 6 6 6 3 3 3 3 3 3 3 3
Full load Current A 78 68 68 59 41 35.5 39 34 37.5 32.5 35.5 31
Maximum overcurrent A 85.8 74.8 74.8 64.9 45.1 39.05 42.9 37.4 41.25 35.75 39.05 34.1
Fuse Rating/phase A 100 100 100 100 50 50 50 50 50 50 50 50
Supply cable terminals mm
2
35 35 35 35 16 16 16 16 16 16 16 16
Unit Total F.L.C. A 146 127 76.5 73 70 66.5
Wiring diagram
A4LZD
561 562 561 562 559 562 559 562 -559 562 -559 -562
Cabinet size 4
Model Ref.
LE90P
Cylinder 1 2 1 2 1 2 1 2 1 2 1 2
Nominal Output Kg/hr 45 45 45 45 45 45 45 45 45 45 45 45
Nominal Output lb/hr NA NA NA NA 99 99 99 99 99 99 99 99
Voltage V 200 200 230 230 380 380 400 400 415 415 440 440
Power input rating Kw NA NA NA NA 33.79 33.85 33.85 33.65 33.93 33.54 33.45 33.39
Electrical Supply Ph's NA NA NA NA 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph
No. of electrodes NA NA NA NA 6 6 6 6 6 6 6 6
Full load Current A NA NA NA NA 62 54 59 51 57 49 53 46
Maximum overcurrent A NA NA NA NA 68.2 59.4 64.9 56.1 62.7 53.9 58.3 50.6
Fuse Rating/phase A NA NA NA NA 80 80 80 80 80 80 80 80
Supply cable terminals mm
2
NA NA NA NA 35 35 35 35 35 35 35 35
Unit Total F.L.C. A NA NA 116 110 106 99
Wiring diagram
A4LZD
561 562 561 562 561 562 559 562
Cabinet size 4
