Vapac LE05 - Cylinder Electrical Demand Loads; LExx Unit Electrical Loads (LE05-LE30)

14
1.5 Cylinder Electrical demand loads
1.5.1 LExx Units
Model Ref.
LE05
LE09
Nominal Output Kg/hr 5 5 5 5 5 5 9 9 9 9 9 9
Nominal Output lb/hr 11 11 11 11 11 11 19.8 19.8 19.8 19.8 19.8 19.8
Voltage V 200 230 380 400 415 440 200 230 380 400 415 440
Power input rating Kw 3.71 3.72 3.8 3.81 3.75 3.77 6.76 6.68 6.7 6.86 6.72 6.7
Electrical Supply Ph's Ph+N or
2Ph
Ph+N or
2Ph
Ph+N or
2Ph
Ph+N or
2Ph
Ph+N or
2Ph
Ph+N or
2Ph
Ph+N or
2Ph
Ph+N or
2Ph
Ph+N or
2Ph
Ph+N or
2Ph
Ph+N or
2Ph
Ph+N or
2Ph
No. of electrodes 2 2 2 2 2 2 2 2 2 2 2 2
Full load Current A 19.5 17 10.5 10 9.5 9 35.5 30.5 18.5 18 17 16
Maximum overcurrent A 29.25 25.5 15.75 15 14.25 13.5 53.25 45.75 27.75 27 25.5 24
Fuse Rating/phase A 32 32 20 20 16 16 63 50 32 32 32 32
Supply cable terminals mm
2
10 10 10 10 10 10 16 16 16 16 16 16
Wiring diagram A4-LZD-559 A4-LZD-559
Cabinet size 1 1
Model Ref.
LE05
-
3
LE09
-
3
Nominal Output Kg/hr 5 5 5 5 5 5 9 9 9 9 9 9
Nominal Output lb/hr 11 11 11 11 11 11 19.8 19.8 19.8 19.8 19.8 19.8
Voltage V 200 230 380 400 415 440 200 230 380 400 415 440
Power input rating Kw 3.79 3.79 3.76 3.96 3.77 3.99 6.76 6.83 6.9 6.93 6.85 6.9
Electrical Supply Ph's 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph
No. of electrodes 3 3 3 3 3 3 3 3 3 3 3 3
Full load Current A 11.5 10 6 6 5.5 5.5 20.5 18 11 10.5 10 9.5
Maximum overcurrent A 17.25 15 9 9 8.25 8.25 30.75 27 16.5 15.75 15 14.25
Fuse Rating/phase A 25 20 16 16 10 10 32 32 20 20 20 16
Supply cable terminals mm
2
10 10 10 10 10 10 10 10 10 10 10 10
Wiring diagram A4-LZD-559 A4-LZD-559
Cabinet size 1 2
Model Ref.
LE18
LE30
Nominal Output Kg/hr 18 18 18 18 18 18 30 30 30 30 30 30
Nominal Output lb/hr 39.6 39.6 39.6 39.6 39.6 39.6 66 66 66 66 66 66
Voltage V 200 230 380 400 415 440 200 230 380 400 415 440
Power input rating Kw 13.36 13.47 13.48 13.53 13.35 13.43 22.43 22.38 22.25 22.43 22.25 22.5
Electrical Supply Ph's 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph
No. of electrodes 3 3 3 3 3 3 6 6 3 3 3 3
Full load Current A 40.5 35.5 21.5 20.5 19.5 18.5 68 59 35.5 34 32.5 31
Maximum overcurrent A 44.55 39.05 23.65 22.55 21.45 20.35 74.8 64.9 39.05 37.4 35.75 34.1
Fuse Rating/phase A 50 50 32 32 25 25 80 80 50 50 40 40
Supply cable terminals mm
2
16 16 16 16 16 16 35 35 16 16 16 16
Wiring diagram A4-LZD-559 A4-LZD-560 A4-LZD-559
Cabinet size 1 2
