Vapac LE05 - LExx Unit Electrical Loads (LE45-LE90)

15
Model Ref.
LE45
LE55
Cylinder 1 1 1 1 1 1 1 1 1 1 1 1
Nominal Output Kg/hr 44 45 45 45 45 45 55 55 55 55 55 55
Nominal Output lb/hr 96.8 99 99 99 99 99 NA NA 121 121 121 121
Voltage V 200 230 380 400 415 440 200 230 380 400 415 440
Power input rating Kw 32.66 33.39 33.85 33.65 33.54 33.39 NA NA 41.37 40.91 41.07 41.37
Electrical Supply Ph's 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph NA NA 3Ph 3Ph 3Ph 3Ph
No. of electrodes 6 6 6 6 6 6 NA NA 6 6 6 6
Full load Current A 99 88 54 51 49 46 NA NA 66 62 60 57
Maximum overcurrent A 108.9 96.8 59.4 56.1 53.9 50.6 NA NA 72.6 68.2 66 62.7
Fuse Rating/phase A 125 125 63 63 63 63 NA NA 80 80 80 80
Supply cable terminals mm
2
35 35 35 35 35 35 NA NA 35 35 35 35
Wiring diagram A4-LZD-560 A4-LZD-560
Cabinet size 2 2
Model Ref.
LE60
Cylinder 1 2 1 2 1 2 1 2 1 2 1 2
Nominal Output Kg/hr 30 30 30 30 30 30 30 30 30 30 30 30
Nominal Output lb/hr 66 66 66 66 66 66 66 66 66 66 66 66
Voltage V 200 200 230 230 380 380 400 400 415 415 440 440
Power input rating Kw 22.43 22.43 22.38 22.38 22.25 22.25 22.43 22.43 22.25 22.25 22.5 22.5
Electrical Supply Ph's 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph
No. of electrodes 6 6 6 6 3 3 3 3 3 3 3 3
Full load Current A 68 68 59 59 35.5 35.5 34 34 32.5 32.5 31 31
Maximum overcurrent A 74.8 74.8 64.9 64.9 39.05 39.05 37.4 37.4 35.75 35.75 34.1 34.1
Fuse Rating/phase A 80 80 80 80 50 50 50 50 40 40 40 40
Supply cable terminals mm
2
35 35 35 35 16 16 16 16 16 16 16 16
Unit Total F.L.C. A 136 118 71 68 65 62
Wiring diagram A4-LZD-560 A4-LZD-559
Cabinet size 4
Model Ref.
LE90
Cylinder 1 2 1 2 1 2 1 2 1 1 1 1
Nominal Output Kg/hr 44 44 45 45 45 45 45 45 45 45 45 45
Nominal Output lb/hr 96.8 96.8 99 99 99 99 99 99 99 99 99 99
Voltage V 200 200 230 230 380 380 400 400 415 415 440 440
Power input rating Kw 32.66 32.66 33.39 33.39 33.85 33.85 33.65 33.65 33.54 33.54 33.39 33.39
Electrical Supply Ph's 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph 3Ph
No. of electrodes 6 6 6 6 6 6 6 6 6 6 6 6
Full load Current A 99 99 88 88 54 54 51 51 49 49 46 46
Maximum overcurrent A 108.9 108.9 96.8 96.8 59.4 59.4 56.1 56.1 53.9 53.9 50.6 50.6
Fuse Rating/phase A 125 125 125 125 80 80 60 60 60 60 60 60
Supply cable terminals mm
2
35 35 35 35 35 35 35 35 35 35 35 35
Unit Total F.L.C. A 198 176 108 102 98 92
Wiring diagram A4-LZD-560
Cabinet size 4
