Vapotherm precision flow - Connecting the Delivery Tube

Page 14 3001002 Rev. P
Section 7 Setting up
7-5-2. Fit the delivery tube to the disposable water path as shown. Press firmly
into place.
Insert fully. Both latches
must click shut.
Assembled disposable
patient circuit ready for
insertion.
Water inlet tube
Tube clamp
Spike
Patient delivery
tube
