INSTALLATION : POWER AND DATA CABLING REQUIREMENTS
2
02.9685.0001 0 01-March-2006 9
Current vs. Voltage
The following tables provide the luminaire’s current draw at specific voltages. Total Luminaire
Current is calculated with the lamp on and all motors sequencing.
Table 2-2: VL500 Wash Luminaire - Current vs. Voltage (230V/1000W Lamp)
Table 2-3: VL500D Wash Luminaire - Current vs. Voltage (120V/1200W Lamp)
Table 2-4: VL500D Wash Luminaire - Current vs. Voltage (230V Version)
Table 2-1: VL500 Wash Luminaire - Current vs. Voltage (120V/1200W Lamp)
Voltage @ 60Hz
Total Luminaire
Current (Motor +
Lamp Current)
Motor Current Lamp Current
90V 15.8A 2.5A 13.4A
100V 14.3A 2.3A 12.0A
110V 13.0A 2.1A 10.9A
120V 11.9A 1.9A 10.0A
130V 11.0A 1.8A 9.3A
Voltage @ 60Hz
Total Luminaire
Current (Motor +
Lamp Current)
Motor Current Lamp Current
180V 6.9A 1.3A 5.6A
190V 6.5A 1.2A 5.3A
200V 6.2A 1.2A 5.0A
210V 5.9A 1.1A 4.8A
220V 5.7A 1.1A 4.6A
230V 5.4A 1.0A 4.4A
240V 5.2A 1.0A 4.2A
Voltage @ 60Hz Current
90V 15.8A
100V 14.3A
110V 13.0A
120V 11.9A
130V 11.0A
Voltage @ 60Hz Current
180V 6.9A
190V 6.5A
200V 6.2A
210V 5.9A
220V 5.7A
