TECHNICAL SPECIFICATIONS
B
02.9685.0001 0 01-March-2006 63
Operational
Power Requirements
Operational Temperature
-20° to 122°F (-29° to 50°C)
Cooling
Natural convection cooled supported by on-demand micro fans for high-temperature
applications.
Control
Compatible with a wide variety of DMX consoles.
DMX Channels
8 - 13 channels depending upon mode selected.
Mounting Position
The luminaire can be mounted and operated in any orientation.
Model Lamp Operating Voltage
VL500 Tungsten, 120V, 1200W 90 - 120VAC, 50/60Hz
Tungsten, 230V, 1000W 216 - 230VAC, 50/60Hz
VL500D Tungsten, 120V, 1200W 90 - 120VAC, 50/60Hz
Tungsten, 230V, 1000W 216 - 264VAC, 50/60Hz
VL500 80V Tungsten, 80V, 1200W 90 - 264VAC, 50/60Hz
VL500A Arc, 575W 90 - 264VAC, 50/60Hz
VL500A Arc, 700W 90 - 264VAC, 50/60Hz
Note:
• Current draw depends on input voltage. For specific current draw, please refer to the VL500 wash
"Current vs. Voltage" tables starting on
page 9.
