VARI❋LITE® - VL500™ WASH LUMINAIRE USER’S MANUAL
46 01-March-2006 02.9685.0001 0
Menu System Functions
Table 4-1: Menu System Chart
1st Level 2nd Level 3rd Level 4th Level 5thLevel
Address
DMX Address
XXX Address value
SetUp
Luminaire Set Up
Lamp Type Arc 575W LAMP? /
CNFIRM 575?
Normal
Turbo
Lamp Saver
700W LAMP? /
CNFIRM 700?
Normal
Lamp Saver
Dimmer
External External Dimmer
230V Internal Dimmer
Voltage Setting (For use
with the Internal 230V
IGBT Dimmer Only)
120V Internal Dimmer
Voltage Setting (For use
with the Internal 120V
IGBT Dimmer Only)
100V Internal Dimmer
Voltage Setting (For use
with 120V IGBT Dimmer
Only)
80V Internal Dimmer
Voltage Setting (NOT
USED - FOR FUTURE
USE)
"Configure" is continued on the next page
To Next Page
