VARI❋LITE® - VL500™ WASH LUMINAIRE USER’S MANUAL
26 01-March-2006 02.9685.0001 0
DMX Mapping
CYM Crossfade Color Mixing and Dimming
CYM Crossfade Color Mixing
Dimming
Beam Control
Beam (Diffuser)
* Depending on lens used.
Table 3-1: DMX Map For CYM Crossfade Color Mixing
% Value DMX Value Action
0 0 Open (White)
100 255 Closed (Full
Saturation)
Table 3-2: DMX Map For Dimmer
% Value DMX Value Action
0 0 Closed
100 255 Open
Table 3-3: DMX Map For Beam (Diffuser) - Tungsten Model Only
% Value DMX Value Action
0 0 Narrowest (far focus)*
100 255 Widest (near focus)*
