VARMEC RCV 252 - Page 67

67
DIMENSIONI / DIMENSIONS / ABMESSUNGEN / DIMENSIONS / DIMENSIONES / DIMENSÕES
L M N h8 O P Q
NF120 - PF120 120 100 80 7 2.5 10
NF140 - PF140 140 115 95 9 3 10
NF160 - PF160 160 130 110 11 3 10
NF200 200 165 130 11 3 10
RCV
CV
RCV CV
IEC
DF
A NEMA DF A AR
(B5) (B14)
202
63 140
180
56 165.1 188
173
71 160 140 165.1 188
80 200
90 200 140
203
56 120 80
173.2
56 165.1 192.2
17063 140 90
71 160 105
NF
P
N
PF
13
RCV 202NF..
RCV 203NF..
CV 202NF..
CV 203NF..
RCV 202PF..
RCV 203PF..
CV 202PF..
CV 203PF..
RCV 202N
RCV 203N
CV 202N
CV 203N
RCV 202P
RCV 203P
CV 202P
CV 203P
