VAT 021 Series User Manual

c
e
r
t
i
f
i
e
d
Q
M
-
S
y
s
t
e
m
g
e
p
r
ü
f
t
e
s
Q
M
-
S
y
s
t
e
m
ISO 9001
EN 29001
Installation, Operating, and Maintenance Instructions
Series 021
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel ++41 81 771 61 61 Fax ++41 81 771 48 30 Email reception@vat.ch http://www.vat.ch
205440EC
2003-04-14
3/12
- valve body, gate aluminum 3.2315, AA6081, AlMgSi1
- valve body, gate stainless steel 1.4435, AISI 316L
- bellows end pieces 1.4435, AISI 316L
- bellows AISI 633 (AM 350)
- bonnet seal FKM (VITON®) *)
- gate seal FKM (VITON®) *)
Mounting position any
Position indicator
- Contact rating 3 A / 50 V DC
Compressed air pressure 4 - 7 bar / 55 - 95 psig (overpressure)
Compressed air connections internal threads M5 *)
- without solenoid : connections „open“ and „closed“
- with solenoid : connection „P“ for air supply
connection „R“ for exhaust
Action at power failure
- valve closed depends on type of solenoid
- valve open depends on type of solenoid
Action at compressed air failure
- valve closed valve remains closed
- valve open undefined
Closing time < 1 s *)
Opening time < 1 s *)
*) Standard specification. Specifications for optional features are provided on the
dimensional drawing of the product.

VAT 021 Series Specifications

General

Brand	VAT
Model	021 Series
Category	Control Unit
Language	English
